Scaldabagno elettrico Tronic 2000 T

ErP

TR2000T 30B

TR2000T 50B

TR2000T 80B

TR2000T 100B

TR2000T 120B

Istruzioni d’installazione e d’uso

TR2000T 30B

Scaricare

TR2000T 50B

Scaricare

TR2000T 80B

Scaricare

TR2000T 100B

Scaricare

TR2000T 120B

Scaricare

Brochure scaldabagni elettrici Tronic

TR2000T 30B

Scaricare

TR2000T 50B

Scaricare

TR2000T 80B

Scaricare

TR2000T 100B

Scaricare

TR2000T 120B

Scaricare

Etichetta efficienza energetica

TR2000T 30B

Scaricare

TR2000T 50B

Scaricare

TR2000T 80B

Scaricare

TR2000T 100B

Scaricare

TR2000T 120B

Scaricare

Scheda prodotto ErP

TR2000T 30B

Scaricare

TR2000T 50B

Scaricare

TR2000T 80B

Scaricare

TR2000T 100B

Scaricare

TR2000T 120B

Scaricare

Efficienza energetica

TR2000T 30B

33 %

TR2000T 50B

37 %

TR2000T 80B

36 %

TR2000T 100B

37 %

TR2000T 120B

37 %

Altezza

TR2000T 30B

457 mm

TR2000T 50B

622 mm

TR2000T 80B

821 mm

TR2000T 100B

1023 mm

TR2000T 120B

1146 mm

Larghezza

TR2000T 30B

445 mm

TR2000T 50B

445 mm

TR2000T 80B

445 mm

TR2000T 100B

445 mm

TR2000T 120B

445 mm

Profondità

TR2000T 30B

452 mm

TR2000T 50B

452 mm

TR2000T 80B

452 mm

TR2000T 100B

452 mm

TR2000T 120B

452 mm

Peso

TR2000T 30B

11,4 kg

TR2000T 50B

14,8 kg

TR2000T 80B

20,2 kg

TR2000T 100B

23,7 kg

TR2000T 120B

27,4 kg

Potenza nominale

TR2000T 30B

1,2 kW

TR2000T 50B

1,5 kW

TR2000T 80B

2 kW

TR2000T 100B

2 kW

TR2000T 120B

2 kW

Profilo di carico

TR2000T 30B

S

TR2000T 50B

M

TR2000T 80B

M

TR2000T 100B

L

TR2000T 120B

L

Consumo di corrente annuo

TR2000T 30B

561 kWh

TR2000T 50B

1405 kWh

TR2000T 80B

1411 kWh

TR2000T 100B

2736 kWh

TR2000T 120B

2753 kWh

Capacità di accumulo

TR2000T 30B

30 l

TR2000T 50B

71 l

TR2000T 80B

97 l

TR2000T 100B

144 l

TR2000T 120B

144 l

Fusibile

TR2000T 30B

5,2 A

TR2000T 50B

6,5 A

TR2000T 80B

8,7 A

TR2000T 100B

8,7 A

TR2000T 120B

8,7 A

Potenza termica

Capacità nominale

Pressione max. lato acqua sanitaria

TR2000T 30B

8 bar

TR2000T 50B

8 bar

TR2000T 80B

8 bar

TR2000T 100B

8 bar

TR2000T 120B

8 bar

Volume utile

TR2000T 30B

30 l

TR2000T 50B

50 l

TR2000T 80B

75 l

TR2000T 100B

100 l

TR2000T 120B

115 l

Perdita per predisposizione all’esercizio

TR2000T 30B

0,59 kW h/d

TR2000T 50B

0,8 kW h/d

TR2000T 80B

1,13 kW h/d

TR2000T 100B

1,4 kW h/d

TR2000T 120B

1,58 kW h/d

Tempo di messa a regime 10 °C/60 °C

TR2000T 30B

100 min

TR2000T 50B

132 min

TR2000T 80B

148 min

TR2000T 100B

196 min

TR2000T 120B

227 min

Tempo di messa a regime 15 °C/85 °C, 4 kW

TR2000T 30B

-99 min

TR2000T 50B

-99 min

TR2000T 80B

-99 min

TR2000T 100B

-99 min

TR2000T 120B

-99 min

Tempo di messa a regime 15 °C/85 °C, 6 kW

TR2000T 30B

-99 min

TR2000T 50B

-99 min

TR2000T 80B

-99 min

TR2000T 100B

-99 min

TR2000T 120B

-99 min

Potenza di allacciamento

TR2000T 30B

1.2

TR2000T 50B

1.5

TR2000T 80B

2

TR2000T 100B

2

TR2000T 120B

2

Classe di isolamento elettrico

TR2000T 30B

CLASS I

TR2000T 50B

CLASS I

TR2000T 80B

CLASS I

TR2000T 100B

CLASS I

TR2000T 120B

CLASS I

Classe d’isolamento (EN 60529)

TR2000T 30B

IP24

TR2000T 50B

IP24

TR2000T 80B

IP24

TR2000T 100B

IP24

TR2000T 120B

IP24

Collegamento elettrico

TR2000T 30B

230 V

TR2000T 50B

230 V

TR2000T 80B

230 V

TR2000T 100B

230 V

TR2000T 120B

230 V

Potenza elettrica

TR2000T 30B

1,2 kW

TR2000T 50B

1,5 kW

TR2000T 80B

2 kW

TR2000T 100B

2 kW

TR2000T 120B

2 kW

Pressione max. consentita

TR2000T 30B

8 bar

TR2000T 50B

8 bar

TR2000T 80B

8 bar

TR2000T 100B

8 bar

TR2000T 120B

8 bar

Capacità

TR2000T 30B

30 l

TR2000T 50B

50 l

TR2000T 80B

80 l

TR2000T 100B

100 l

TR2000T 120B

120 l

Peso a recipiente vuoto

TR2000T 30B

11,5 kg

TR2000T 50B

12,5 kg

TR2000T 80B

20 kg

TR2000T 100B

24 kg

TR2000T 120B

28 kg

Frequenza

TR2000T 30B

50 Hz

TR2000T 50B

50 Hz

TR2000T 80B

50 Hz

TR2000T 100B

50 Hz

TR2000T 120B

50 Hz

Intensità corrente di fase

TR2000T 30B

5,2 A

TR2000T 50B

6,5 A

TR2000T 80B

8,7 A

TR2000T 100B

8,7 A

TR2000T 120B

8,7 A

Peso a recipiente pieno

TR2000T 30B

41,5 kg

TR2000T 50B

42,5 kg

TR2000T 80B

100 kg

TR2000T 100B

124 kg

TR2000T 120B

148 kg

Profilo di carico nominale

TR2000T 30B

S

TR2000T 50B

M

TR2000T 80B

L

TR2000T 100B

L

TR2000T 120B

L

Grado di protezione (IP)

TR2000T 30B

IPX4

TR2000T 50B

IPX4

TR2000T 80B

IP24

TR2000T 100B

IP24

TR2000T 120B

IP24

Tempo di riscaldamento (ΔT = 50 °C)

TR2000T 30B

1 h 27 min

TR2000T 50B

1 h 10 min

TR2000T 80B

2 h 20 min

TR2000T 100B

2 h 55 min

TR2000T 120B

3 h 30 min

Tensione di allacciamento

TR2000T 30B

230 Vac

TR2000T 50B

230 Vac

TR2000T 80B

230 Vac

TR2000T 100B

230 Vac

TR2000T 120B

230 Vac

Dimensioni (diametro × altezza)

TR2000T 30B

440 x 457 mm

TR2000T 50B

440 x 622 mm

TR2000T 80B

440 x 869 mm

TR2000T 100B

440 x 1031 mm

TR2000T 120B

440 x 1194 mm

Codice prodotto

TR2000T 30B

7736503346

TR2000T 50B

7736503347

TR2000T 80B

7736503349

TR2000T 100B

7736503351

TR2000T 120B

7736503353
